Connecting To A Stagehand
Establishing A Network Connection To A Stagehand In Spikemark
Make sure you have configured on your Computer IP Address and Stagehand IP Address first
Then we’re ready to establish a connection to a Stagehand within Spikemark.
  1. 1.
    Make sure you are in the Jog Workspace and Live Show Mode
  1. 1.
    Select the motor you wish to connect to by clicking on it.
  2. 2.
    In the Network section of the Stagehand Properties Panel on the right side of the screen or at the bottom of the Jog Workspace, enter the IP Address of your Stagehand and click Connect.
In this step, make sure you copy the IP Address exactly as it appears on the face panel of the Stagehand OLED or LCD display.
3. Click on Connect. You will see the Network status change to Connecting, to Connected
If there’s a network error, check your IP settings on the computer and Stagehand and then check your cabling.

You can also connect to or disconnect from all Stagehands by Clicking on the Stagehand in the Toolbar and selecting:
  1. 1.
    Connect to All - Ctrl+Shift+T
  2. 2.
    Disconnect From All - Alt+Shift+T
